CMP Products Cable Gland Industrial M40 24-32mm Nylon/Polyamide IP66/67/68/69K

$CMP_Products\CMP_40TSPV02TN1L.JPG$

Description

Cable Gland Industrial, M40, 18 mm Thread Length, 24 mm Min. Sheath OD, 32 mm Max. Sheath OD, 50 mm Width Across Flats, IP66/67/68/69K, Nylon/Polyamide Body, Thermoset Elastomer Seal, -40 to 100 deg C

Key Specifications

Barcode (EAN-13)	5052625275047
SKU	CMP40TSPV02TN1L
Brand	CMP Products
Product Type	Cable Glands Industrial

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Halogen and phosphorus free. Extremely flame retardant and self-extinguishing according to UL94 V-0. Incorporates CMP's trusted SOLO technology 3rd party certified to IEC/EN 62444 Finger-locking seal provides superior cable retention and strain relief Low weight with high stiffness and strength
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	40TSPV02TN1L
Body Material	Nylon / Polyamide
IP Rating	IP66/67/68/69K
Max. Sheath OD	32 mm
Min. Sheath OD	24 mm
Seal Material	Thermoset Elastomer
Temperature	-40 to 100 deg C
Thread Length	18 mm
Width Across Flats	50 mm
Thread Size	M40
