Panduit Ring Terminal Insulated Single Grip 1.5-2.5mm M3 Stud Blue 23.4mm OAL

Description

Ring Terminal, Insulated, Single Grip, Conductor Size: 1.5-2.5 mm, Stud Size: M3, Terminal Type: Circular, 600 Volt Maximum, Wire Strip Length: 7.9mm, Barrel Type: Funnel, Seam Type: Butted, Mounting Method: Free Hanging, Body Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Blue Insulation, Tin Plated Finish, 221 deg F, 23.4mm Overall Length, 11.7mm Lug Length, 7.9mm Lug Width, 0.8mm Lug Thickness, 3.8mm Lug Inside Diameter, Barrel Length: 9.6mm, Max. Insulation Diameter: 4.3mm, 25 Pack

Key Specifications

SKU	PANEV14-6RB-Q
Brand	Panduit
Range Name	StrongHold
Product Type	Forked & Ring Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	25
UNSPSC Class	39121400
UOM	EA
Vendor Product	EV14-6RB-Q
Barrel Length	9.6 mm
Body Material	Copper
Barrel Type	Funnel
Conductive Material	Copper
Conductor Size	1.5-2.5mm
Finish	Tin Plated
Insulation Colour	Blue
Insulation Material	Vinyl
Insulation Diameter	4.3 mm
Lug Inside Diameter	3.8 mm
Lug Length	11.7 mm
Lug Width	7.9 mm
Lug Thickness	0.8 mm
Mounting Method	Free Hanging
Overall Length	23.4 mm
Pack Size	25 Pack
Seam Type	Butted
Stud Size	M3 Stud
Temperature	221 deg F
Terminal Type	Circular
Voltage Rating	600 Volt
Wire Strip Length	7.9 mm
