CMG Electric Motor Squirrel Cage Induction 2P 75kW 3Ph 415V 250M Frame Foot Mount

Description

Electric Motor Squirrel Cage Induction, 415 Volt AC, 122 Amp, 75 kW, 50 Hz, 3 Phase, 2985 rpm, Number of Speeds: Single, 2 Pole, IP66, Frame: 250M, Shaft Size: 60-70 mm, Clockwise Rotation, Counter-Clockwise, Duty Cycle: S1, Ball Bearing, Torque: 240 N/m, Foot Mount, Insulation Class: Class H, -20 to 120 deg C, Totally Enclosed Fan Cooled Cast Iron, Bright Red Orange, 485 mm Diameter x 965 mm Length x 580 mm Height

Key Specifications

SKU	CMGM3207500B3PPA
Brand	CMG
Range Name	PPA Series
Product Type	Motors SCIM

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	PPA range of motors are premium, high efficiency motors designed to withstand even the most arduous of environments The PPA meets world market needs and standards Thru flush grease relief valves 20 year design life Low noise low vibration design Ex e, Ex nA and Ex t hazardous locations For arduous environments, mining industry, food and beverage industry, chemical processing and petrochemical applications
Standard Pack Size	1
UNSPSC Class	26101100
UOM	EA
Vendor Product	M3207500B3PPA
Colour	Bright Red/Orange
Diameter	485 mm
Current	122 Amp
Bearing Type	Ball
Frame	Size 250M
Height	580 mm
Frequency	50 Hz
Insulation Class	Class H
IP Rating	IP66
Horsepower	75 kW
Mounting Method	Foot
Material	Totally Enclosed Fan Cooled Cast Iron
Number of Speeds	Single
Number Of Poles	2 Pole
Phase	3 Phase
Rotation	Clockwise, Counter-Clockwise
Shaft Size	60-70 mm
Speed	2985 rpm
Temperature	-20 to 120 deg C
Voltage	415 Volt AC
Torque Rating	240 N/m
