Sprecher+Schuh Motor Starter Star Delta 22kW 415V Insulated Polycarbonate Enclosure IP66

chevron-left
loader
Loading...

Description

chevron-down
Motor Starter Star Delta, 22 kW, 415 Volt AC, 6 Wires, 1.5 to 30 sec, Start/Stop/Reset Pushbutton, 5.4 to 27 Amp, IP66, Insulated Polycarbonate Enclosure

Key Specifications

chevron-down
Barcode (EAN-13)
9321807182456
SKU
S&SSDS7-22L/415VAC
Brand
Sprecher+Schuh
Range Name
Streamline
Product Type
Motor Starters Star Delta

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Wide Range of NHP motor starting method versions available allowing for correct selectionof motor starter to suit the application load condition requirements during starting
  • Overload is to be set to 58 percent of the motor Full Load Current (FLC)
Standard Pack Size 1
UNSPSC Class 39121500
UOM EA
Vendor Product SDS722L415VA
Action Start/Stop/Reset Pushbutton
Coil Voltage 415 Volt AC
Full Load Current Rating 5.4-27 Amp
IP Rating IP66
Number of Wires 6 Wires
Timing 1.5-30 sec
Wattage 22 kW
